0.8" Textile Dome Tweeter

FSI543010-1602

Features
0.8", Plastic Frame
Textile Dome Diaphragm
Dual Ferrite Magnet Motor System
With Ferrofluid-Cooled
Size
0.8 Inch
Fs
2060 Hz
Re
5.5 Ohms
Sensitivity
84 dB
Quality Factor
0.69 Qts
Rated Power
30 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This is a 0.8 inch 6 ohm driver, it is a Tweeter features 0.8 inch voice coil with CCAW. In term of suspension system, Dome is consisted by Textile material with Textile surround. In term of magnet motor system, magnet is consisted by Ferrite material. It can be used on Soundbar model .

Family
Range

T-S Parameters
Resonance frequency [fs] 2059 Hz
Mechanical Q factor [Qms] 0.76
Electrical Q factor [Qes] 8.25
Total Q factor [Qts]  0.69
Force factor [Bl] 0.99 Tm
Mechanical resistance [Rms] 1.93 kg/s
Moving mass [Mms]  0.11 g
Compliance [Cms] 0.052 mm/N
Effective diaph. diameter [D]  25 mm
Effective piston area [Sd] 4.9 cm²
Equivalent volume [Vas] 0.0018 l
Sensitivity (2.83V/1m)  84 dB
Ratio Bl/√Re 0.42 N/√W
Ratio fs/Qts 2984 Hz
Electrical Data
Nominal impedance [Zn]  6 Ω
Minimum impedance [Zmin]  5.5 Ω
Maximum impedance [Zo] 5.6 Ω
DC resistance [Re] 5.5 Ω
Voice coil inductance [Le]  0.025 mH
Power Handling
100h RMS noise test (IEC 18.4) 30 W
Long-term max power (IEC 18.2) 60 W
Voice Coil & Magnet Data
Voice coil diameter 20.32 mm
Voice coil height 1.1 mm
Voice coil layers 2
Height of gap 2.5 mm
Linear excursion ± 0.7 mm
Max mech. excursion ± - mm
Unit weight 0.15 kg
