Standard
10” Paper Cone Subwoofer
FSB026001-0401
Features
10”, Steel Frame
1.4” PESVW Voice Coil, Aluminum Former
Paper Cone, Rubber Surround, Long Excursion(±5mm)
Strong Ferrite Magnet Motor System
Pole Piece Vent, Low Distortion(<3%)
Parameters
Size
10 Inch
Fs
31 Hz
Re
3.43 Ohms
Sensitivity
91 dB
Quality Factor
0.44 Qts
Rated Power
60 W
This is a 10 inch 4 ohm driver, it is a Subwoofer features 1.4 inch voice coil with PESVW. In term of suspension system, cone is consisted by Paper Cone body with NBR surround and spider is consisted by Conex. In term of magnet motor system, magnet is consisted by Ferrite material. It can be used on active Subwoofer model.
Family
Range
| T-S Parameters | |
|---|---|
| Resonance frequency [fs] | 31 Hz |
| Mechanical Q factor [Qms] | 5.64 |
| Electrical Q factor [Qes] | 0.475 |
| Total Q factor [Qts] | 0.438 |
| Force factor [Bl] | 9.336 Tm |
| Mechanical resistance [Rms] | 2.14 kg/s |
| Moving mass [Mms] | 61.355 g |
| Compliance [Cms] | 0.421 mm/N |
| Effective diaph. diameter [D] | 210 mm |
| Effective piston area [Sd] | 346.36 cm² |
| Equivalent volume [Vas] | 71.523 l |
| Sensitivity (2.83V/1m) | 91 dB |
| Ratio Bl/√Re | 5.05 N/√W |
| Ratio fs/Qts | 70.78 Hz |
| Electrical Data | |
|---|---|
| Nominal impedance [Zn] | 4 Ω |
| Minimum impedance [Zmin] | 3.21 Ω |
| Maximum impedance [Zo] | 26.48 Ω |
| DC resistance [Re] | 3.43 Ω |
| Voice coil inductance [Le] | 1.3 mH |
| Power Handling | |
|---|---|
| 100h RMS noise test (IEC 18.4) | 60 W |
| Long-term max power (IEC 18.2) | - W |
| Voice Coil & Magnet Data | |
|---|---|
| Voice coil diameter | 35.5 mm |
| Voice coil height | 16 mm |
| Voice coil layers | 4 |
| Height of gap | 6 mm |
| Linear excursion | ± 5 mm |
| Max mech. excursion | ± - mm |
| Unit weight | 2.09 kg |
