ASDFD5527-0601
ASDFD5527-0601
Standard
2.75" Aluminum Cone Fullrange

ASDFD5527-0601

Features
2.75", Steel Frame
0.8" CCAW Voice Coil, Kapton Former
Aluminum Cone, Aluminum Cap, Rubber Surround
Neodymium Magnet Motor System
Low Distortion (<3%)
Size
2.75 Inch
Fs
160 Hz
Re
5.49 Ohms
Sensitivity
85 dB
Quality Factor
0.77 Qts
Rated Power
25 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

The ultimate 2.75 inch,6 ohm, Steel frame driver have been newly designed with 0.8 inch PECCAW voice coil, Upgraded Aluminum cone and Neodymium motor system to provide wide range sound experience. This spectacular driver is the new benchmark for soundbar systems.

Family
Range

T-S Parameters
Resonance frequency [fs] 162.7 Hz
Mechanical Q factor [Qms] 2.934
Electrical Q factor [Qes] 1.044
Total Q factor [Qts]  0.770
Force factor [Bl] 3.344 Tm
Mechanical resistance [Rms] 0.724 kg/s
Moving mass [Mms]  2.079 g
Compliance [Cms] 0.460 mm/N
Effective diaph. diameter [D]  54 mm
Effective piston area [Sd] 23.76 cm²
Equivalent volume [Vas] 0.3678 l
Sensitivity (2.83V/1m)  85 dB
Ratio Bl/√Re 1.427 N/√W
Ratio fs/Qts 211.29 Hz
Electrical Data
Nominal impedance [Zn]  6 Ω
Minimum impedance [Zmin]  6.5 Ω
Maximum impedance [Zo] 20.38 Ω
DC resistance [Re] 5.49 Ω
Voice coil inductance [Le]  0.071 mH
Power Handling
100h RMS noise test (IEC 18.4) 25 W
Long-term max power (IEC 18.2)  W
Voice Coil & Magnet Data
Voice coil diameter 20.32 mm
Voice coil height 5.6 mm
Voice coil layers 2
Height of gap 3 mm
Linear excursion ± 1.3 mm
Max mech. excursion ± - mm
Unit weight 0.096 kg
