ASDFD2500-0800
ASDFD2500-0800
Standard
2.5" Paper Cone Fullrange

ASDFD2500-0800

Features
2.5", Steel Frame
0.8" CCAW Voice Coil, Kapton Former
Paper Cone, Rubber Surround
Dual Neodymium Magnet Motor System
High Sensitivity
Power Handling with 2th HP Filter @ 140Hz
Size
2.5 Inch
Fs
170 Hz
Re
7.26 Ohms
Sensitivity
83 dB
Quality Factor
0.9 Qts
Rated Power
25 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This is a 2.5 inch 8 ohm driver, it is a Fullrange features 0.8 inch voice coil with CCAW. In term of suspension system, cone is consisted by Paper Cone body with NBR surround and spider is consisted by Conex. In term of magnet motor system, magnet is consisted by Neodymium material. It can be used on Soundbar model.

Family
Range

T-S Parameters
Resonance frequency [fs] 171 Hz
Mechanical Q factor [Qms] 5.69
Electrical Q factor [Qes] 1.07
Total Q factor [Qts]  0.9
Force factor [Bl] 3.56 Tm
Mechanical resistance [Rms] 0.33 kg/s
Moving mass [Mms]  1.74 g
Compliance [Cms] 0.49 mm/N
Effective diaph. diameter [D]  49.5 mm
Effective piston area [Sd] 19.24 cm²
Equivalent volume [Vas] 0.25 l
Sensitivity (2.83V/1m)  83 dB
Ratio Bl/√Re 1.32 N/√W
Ratio fs/Qts 190 Hz
Electrical Data
Nominal impedance [Zn]  8 Ω
Minimum impedance [Zmin]  6.7 Ω
Maximum impedance [Zo] 37.8 Ω
DC resistance [Re] 7.26 Ω
Voice coil inductance [Le]  0.2 mH
Power Handling
100h RMS noise test (IEC 18.4) 25 W
Long-term max power (IEC 18.2) - W
Voice Coil & Magnet Data
Voice coil diameter 20.32 mm
Voice coil height 4.6 mm
Voice coil layers 2
Height of gap 4 mm
Linear excursion ± 0.3 mm
Max mech. excursion ± - mm
Unit weight 0.0865 kg
