ASDDT2500-0800
ASDDT2500-0800
Standard
0.6" Textile Dome Tweeter

ASDDT2500-0800

Features
0.6", Plastic Frame
0.6" CCAW Voice Coil, Aluminum Former
Textile Dome Diaphragm
Dual Neodymium Magnet Motor System
High Sensitivity
Power Handling with 4th HP Filter @2500Hz
Size
0.6 Inch
Fs
2530 Hz
Re
7.5 Ohms
Sensitivity
85 dB
Quality Factor
1.69 Qts
Rated Power
25 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This compact Tweeter features an 8 ohm 0.6 inch voice coil, a textile dome diaphragm and Neodymium magnet motor system. This tweeter features CCAW which further extend the high frequency response. This tweeter comes with a round frame to allow for easy installation into customized faceplates.

Family
Range

T-S Parameters
Resonance frequency [fs] 2530 Hz
Mechanical Q factor [Qms] 2.37
Electrical Q factor [Qes] 5.92
Total Q factor [Qts]  1.69
Force factor [Bl] 1.6 Tm
Mechanical resistance [Rms] 0.86 kg/s
Moving mass [Mms]  0.13 g
Compliance [Cms] 0.03 mm/N
Effective diaph. diameter [D]  19.3 mm
Effective piston area [Sd] 2.93 cm²
Equivalent volume [Vas] 0.002 l
Sensitivity (2.83V/1m)  85 dB
Ratio Bl/√Re 0.58 N/√W
Ratio fs/Qts 1497 Hz
Electrical Data
Nominal impedance [Zn]  8 Ω
Minimum impedance [Zmin]  6.8 Ω
Maximum impedance [Zo] 9.8 Ω
DC resistance [Re] 7.5 Ω
Voice coil inductance [Le]  0.028 mH
Power Handling
100h RMS noise test (IEC 18.4) 25 W
Long-term max power (IEC 18.2) - W
Voice Coil & Magnet Data
Voice coil diameter 16.4 mm
Voice coil height 1.6 mm
Voice coil layers 2
Height of gap 1.5 mm
Linear excursion ± 0.05 mm
Max mech. excursion ± - mm
Unit weight 0.0219 kg
