3.25" Glass Fiber Cone Fullrange

AUK600814-1780

Feature
3.25", Steel Frame
0.8" CCAW Voice Coil, Til Former
Glass Fiber Cone, Rubber Surround, Long Excursion(±3.9mm)
Strong Ferrite Magnet Motor System, Pole Piece Vent
Wide Frequency Range
Extended Copper Cap on Pole Piece, Low Distortion(<3%)
Size
3.25 Inch
Fs
120.0 Hz
Re
6 Ohms
Sensitivity
82.00 dB
Quality Factor
1.110 Qts
Rated Power
20 W
  • Description
  • Simulation
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This 3.25inch 6ohm fullrange driver, with 0.8" voice coil copper clad aluminum wire, TiL former, damping glue coated glass fiber cone and NBR rubber surround. It contains copper shorting cap on pole piece, which reduces coil inductance, thus providing both extended frequency response performance and reduced distortion. The TiL former, bottom plate and basket under damper are all vented hole so as to reduce air compression effects and aid cooling of the motor under high excursion conditions.

Family
Range
 AUK600814-1780

T-S Parameters
Resonance frequency [fs] 120 Hz
Mechanical Q factor [Qms] 3.715
Electrical Q factor [Qes] 1.59
Total Q factor [Qts]  1.11
Force factor [Bl] 2.91 Tm
Mechanical resistance [Rms] 0.759 kg/s
Moving mass [Mms]  3.75 g
Compliance [Cms] 0.47 mm/N
Effective diaph. diameter [D]  68 mm
Effective piston area [Sd] 36.3 cm²
Equivalent volume [Vas] 0.88 l
Sensitivity (2.83V/1m)  82 dB
Ratio Bl/√Re 1.32 N/√W
Ratio fs/Qts 107.8 Hz
Electrical Data
Nominal impedance [Zn]  6 Ω
Minimum impedance [Zmin]  5.0 Ω
Maximum impedance [Zo] 19.3 Ω
DC resistance [Re] 4.8 Ω
Voice coil inductance [Le]  0.075 mH
Power Handling
100h RMS noise test (IEC 17.1) 20 W
Long-term max power (IEC 17.3) - W
Voice Coil & Magnet Data
Voice coil diameter 20.32 mm
Voice coil height 11.8 mm
Voice coil layers 2//2
Height of gap 4 mm
Linear excursion ± 3.9 mm
Max mech. excursion ± - mm
Unit weight 0.391 kg
